SE47 V Vibratory Screed

360 View

Product Description

The Cat® SE47 V screed with rear-mounted extenders provides stability, easy set-up, and a versatile paving range, making it the perfect match for urban streets, parking lots, rural roads, and many other mid-sized paving applications.

Specifications
Us
Metric
Weights
Standard Weight
5850 lb
2654 kg
Operating Specifications
Standard Paving Range
2.44 - 4.7 m (8' - 15' 6")
Maximum Paving Width
20 ft
6.1 m
Maximum Paving Depth
10 in
250 mm
Heating Time - Maximum Width
25 minutes
Heating Time - Standard Width
15 minutes
Dimensions
Minimum Width - Endgates Attached
102 in
2590 mm
Transport Length - Tractor and Screed
18.1 ft
5523 mm
Operating Specifications
Crown Range
+6% to -2%
Vibratory Speed Range
0 to 3000 vpm
Extender Height Range
+30 mm to -20 mm
Extender Slope Range
+10% to -3%
Dimensions
Screed Plates Width, Front to Back, Main Screed
12.8 in
324 mm
Screed Plates Width, Front to Back, Extenders
12.8 in
324 mm
Length - Front to Back, Endgates Attached
84 in
2123 mm
Length - Front to Back, Endgates Removed
60 in
1532 mm
Height
56 in
1428 mm
Standard/Optional

Standard Equipment

Power Controls
Service and Repair
Safety
Material Delivery
Operating Environment

Optional Equipment

Technology
Safety
Material Delivery
