541 Series 2 Track Feller Buncher

Product Description

The Series 2 track feller bunchers feature smoother hydraulic performance, better fuel economy, a more comfortable operator station and better visibility. The Cat® 541 Series 2 is a full tail swing machine designed for high production clear cut and for clear or select cut in rough terrain.

Specifications
Us
Metric
Engine
Gross Power
303 hp
226 kW
Engine Model
Cat® C9 ACERT™ Tier 3
Gross Power - 1,800 rpm
303 hp
226 kW
Operating Specifications
Maximum Reach - With Attachment
28.2 ft
8.6 m
Hydraulic System
Pumps
Pumps
Service Refill Capacities
Cooling System
16.1 gal (US)
61 l
Engine Oil
10.3 gal (US)
39 l
Hydraulic Tank
85.3 gal (US)
323 l
Hydraulic System
97.7 gal (US)
370 l
Swing Drive
2.6 gal (US)
10 l
Fuel Capacity
312 gal (US)
1181 l
Weights
Operating Weight - Without Attachment
67960 lb
30826 kg
Operating Weight - Without Heads***
68640 lb
31135 kg
Operating Weight - Without Heads*
67960 lb
30826 kg
Operating Weights - Without Head
Track Feller Bunchers - Standard Linkage
67960 lb
30826 kg
Track Feller Bunchers - Long Felling Linkage
68640 lb
31135 kg
Power Train
Rated Power - 2,100 rpm
282 hp
210.3 kW
Gross Power - 1,800 rpm
303 hp
226 kW
Engine Model
Cat® C9 ACERT™
Displacement
537 in³
8.8 l
Boom System
Bare Pin Lift at Maximum Reach - Without Head***
6400 kg @ 8.2 m (14,200 lb @ 27 ft)
Maximum Reach - With Head*
28.2 ft
8.6 m
Bare Pin Lift at Maximum Reach - Without Head*
9400 kg @ 6.6 m (21,800 lb @ 21.5 ft)
Undercarriage
Tractive Effort
75500 lb
34246 kg
Track Length
192.6 in
4893 mm
Size/Pitch
330/215.9 mm (330/8.5 in)
Ground Clearance
35 in
889 mm
Track Gauge
2591 mm-2870 mm (102 in-113 in)
Standards
Cab
Standards
Standard/Optional

Standard Equipment

ELECTRICAL
GUARDS
OPERATOR ENVIRONMENT
POWER TRAIN
UNDERCARRIAGE
OTHER STANDARD EQUIPMENT
HYDRAULICS
ANTIFREEZE

Optional Equipment

TRACK SYSTEMS
OTHER EQUIPMENT
FIELD INSTALLED ATTACHMENTS
